Dayton Audio - 8" Ultimax Subwoofer - UM8-22

Dayton Audio - 8" Ultimax Subwoofer - UM8-22

Regular price $364.95 AUD
Regular price Sale price $364.95 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.

Description:

This 8" Ultimax Series DVC subwoofer is purpose-built to move air and create clean, articulate, fast bass. Optimised for small enclosures and with over 1-1/4" of throw, the UM8-22 8" subwoofer is perfect for providing deep bass without taking up much space. Experience the apex of subwoofer design.

Dayton Audio's Ultimax Series DVC subwoofers are purpose-built to move air and create clean, articulate, fast bass. Optimised for small enclosures and with over 1-1/4" of throw, the UM8-22 8" subwoofer is perfect for providing deep bass without taking up much space.

It has dual 2 ohm voice coils allow for stereo 2 ohm and mono 1 ohm wiring configurations when connecting to high current car audio and professional audio amplifiers to extract maximum power. For home audio applications, simply wire the voice coils in series for a benign 4 ohm load for greater amplifier compatibility.
To improve power handling, increase thermal management, and reduce power compression, this speaker features large black anodised formers and vented pole pieces, under-spider ventilation, and two-layer copper voice coils.

Over 1-1/4" of travel (.67" Xmax) is kept completely linear through the use of dual spiders that also limit distortion and rocking modes. "Tall-boy" rubber surrounds with integrated gaskets maintain driver surface area during extreme excursion moments. The thick, one-piece Nomex honeycomb cone is covered with woven, heavy-duty glass fibers creating an ultra-stiff surface that resists deformation.

A large copper sleeve and copper pole cap in the motor reduce energy storage from inductance, with the side benefit of lowering distortion for "faster" response. Large dual-stacked, high-energy magnets handle the heavy lifting and bring Qts down to a level where Ultimax subwoofers can be used in vented or sealed cabinets and enclosures.

Features:

  • 16 mm Xmax makes this one of the highest excursion 8" subwoofers on the market
  • Thick, one-piece Nomex honeycomb covered cone with woven heavy-duty glass-fibre
  • Tall-boy rubber surround for extra-long linear excursion without reducing cone surface area
  • Dual linear stiffness spiders limit distortion and rocking modes
  • 300 watts RMS power handling
  • Black anodised aluminium former and black pole improves heat dissipation
  • Dual 2 ohm, 2-layer copper voice coils

Specifications:

Code UM8-22
Description 8" Ultimax DVC Subwoofer 2 Ohms Per Coil
Cms 0.33mm/N
Coil 50.8nnmØ
Depth 119.5mm
Diam. 210mmØ
Fs 31.6Hz
Impedance 2+2Ω (Re 4.2Ω)
Impedance (Ohm) 2+2 ohm
Le 1.14mH
Manufacturer Dayton Audio
Material Fibreglass
Mms 74.5g
Power 300Wrms
Qes 0.75
Qms 2.51
Qts 0.58
Re 4.2Ω
Sd 211.2cm²
Sens. 84.2dB
Series Ultimax Series
Size 8"
Type DVC subwoofer
Vas 21.3L
Zn 2x 2Ω
