Hypex - 500W Mono Power Amplifier Kit - Nilai500DIY

5% DISCOUNT AUTOMATICALLY APPLIED AT CHECKOUT WHEN YOU PURCHASE 2 OR MORE HYPEX PRODUCTS.

ALL OUR HYPEX PRODUCTS ARE BACKORDERED ON AN ORDER BY ORDER BASIS DIRECTLY FROM HYPEX. HEAD TO THE LINK IN OUR BANNER FOR DETAILS OF SHIPPING TIME FRAMES OVER THE CHRISTMAS PERIOD.

Description:

The Nilai500DIY is the long-awaited successor to the acclaimed NC400. Its polished shiny exterior is a true reflection of what is to be found inside. The engine room houses a brand new control-loop topology that really boosts performance to the next level. It outperforms Ncore by not less than 10 times!

The module comes with a fully discrete buffer stage and on-board voltage regulators, just like the NC400 it's replacing. Together with carefully selected high-grade components, the Nilai500DIY is our best sounding amplifier to date. We have created a truly special technique which sets a new benchmark for high-end audio applications and is a truly unique amplifier module for our DIY community.

Combining the Nilai500DIY with the matching PS500DIY will result in the best possible ready-to-go DIY-experience possible!

With the easy to follow instructions you will be able to realize a high end power amplifier at a fraction of the cost and all of this can be done in just 30-60 minutes. Combined with our DIYclassD PreAmplifier kit you can create a complete set of superbly sounding equipment.

All you need to bring to the table is this box and a few tools: • Wire cutter (or combination plier)• 5.5 mm hex nut driver (or combination plier) • 7 mm hex nut driver (or combination plier) • 3.5 mm flat type screwdriver

Features & Specifications:

• THD+N: 0,00015% (-116dB) @ 100W / 4Ohm / 20.000Hz
• Power (2Ω): 1x 500W
• Power (4Ω): 1x 525W
• Power (8Ω): 1x 260W
• Output noise: 9,5µV @11,8dB gain
• Gain adjust in 3 steps (11,8 - 21,8 and 27,8)
• High fidelity components
• Discrete buffer stage and regulators
• Dedicated high-end power supply PS500DIY included
• 2Ω stable for use with a wide range of speakers

Inputs

• • 1 x Trigger 12V
• • 1 x Balanced XLR

Outputs

• • 1 x Gold Plated Binding Post Set

Package Includes:

• Complete DIYclassD Nilai500DIY mono case “matte black”,
• Complete internal cable harness,
• PS500DIY power supply,
• Nilai500DIY amplifier module,
• Input board & Front board,
• All needed mounting materials,
• Assembly instruction,
• 1.5mm Allen key,
• 2.5mm Allen key,
• TX-10 Torx key,
• TX-20 Torx key
