Scan-Speak - 13" Revelator Woofer - 32W/4878T11
Scan-Speak - 13" Revelator Woofer - 32W/4878T11
Regular price
$1,079.95 AUD
Regular price
Sale price
$1,079.95 AUD
Unit price
/
per
Description:
The 32W/4878T11 woofer is optimized for high sensitivity applications. It offers an impressive 95 dB sensitivity at 2.83V/1m. It features a large 3” motor system with patented Symmetrical Drive, double ferrite magnets and a sandwich paper cone surrounded by a coated foam suspension.
Features:
- 95 dB Sensitivity @ 2.83V/1m
- Coated foam Surround
- Powerful motor with dual ferrite magnets
- Paper sandwich cone
- Patented Symmetrical Drive motor
- 3” Voice coil, Titanium former and paper reinforced
Specifications:
Code | 32W/4878T11 |
Impedance | 4Ω (Re 3.1Ω) |
Power | 350Wrms |
Fs | 24Hz |
Qes | 0.22 |
Qms | 4.25 |
Qts | 0.21 |
Vas | 185L |
Re | 3.1Ω |
Rms | 3.3kg/s |
Sd | 526cm² |
Sens. | 95.0dB |
Series | Revelator |
Size | 13" |
Type | Woofer |
Width | 320mm |
Zn | 4Ω |
Depth | 160mm |
Impedance (Ohm) | 4 ohm |
Inch | 13 |
Le | 0.36mH |
Mms | 93g |
Power (RMS) | 200+ Watt |
Cms | 0.47mm/N |
Coil | 75mmØ |
Manufacturer | Scan-speak |
