Vifa

Vifa by Tymphany - 2" Full Range - TC6FD00-04

Vifa by Tymphany - 2" Full Range - TC6FD00-04

Regular price $28.95 AUD
Regular price Sale price $28.95 AUD
Sale Sold out
Shipping calculated at checkout.

Description:

Brings classic hi-fi capabilities to compact music and media systems. Patented PentaCut paper cone technology improves musicality and accuracy, and the driver features a cost-effective ceramic ferrite magnet. A copper cap on the pole piece controls system impedance, thereby extending the upper frequency range. Ideally suited for use in flat panel televisions and sound bars, MP3 and cell phone dock

Specifications:

Code TC6FD00-04
Type Full Range
Size 2"
Power 15Wrms
Coil 19.4mmØ
Width 55mmØ
Impedance 4Ω (Re 3.5Ω)
Depth 32mm
Mag. 170g
Sens. 84.4dB
Re 3.5Ω
Qms 4.1
Qes 1.29
Qts 0.98
Vas 0.22L
Sd 15.2cm²
Cms 0.677mm/N
Fs 175Hz
Mms 1.22g
Zn
Le 0.02mH
Manufacturer Vifa
Impedance (Ohm) 4 ohm
