Dayton Audio - 5W 19mm Sound Exciter - DAEX19CT-4

Description

Take your product or project to the next level by turning into a speaker! The DAEX19CT-4 sound exciter, by Dayton Audio, features voice coil vent holes for higher power handling.

Dayton Audio's 19 mm DAEX19CT-4 coin type exciter features the same ability to turn nearly any surface into a speaker, as other exciters and tactile transducers, only in a more compact package for working with smaller surfaces. This exciters small size enables audio reproduction in places never imagined: toys, monitors, cabinet doors... even windows!

A neodymium magnet is employed to create maximum magnetic flux around the proprietary voice coil for increased sensitivity when compared to similar sized exciters. In turn, this reduces power requirements and makes it possible to use very small audio amplifiers, without sacrificing total output. Cooling holes placed strategically on this exciters housing allows for higher power handling, for applications where more output is desired, while maintaining a small form factor.

To ensure maximum acoustic energy transfer between the transducer and the surface to which it is attached, 3M VHB (Very High Bond) adhesive is pre-applied... just peel and stick! Two PCB solder points keep installation and wiring as compact as possible.

Note: An exciters frequency response and sensitivity are completely dependent on the exciters designated surface. Thinner, smaller materials will tend to be louder and create a mid/tweeter response. Thicker, larger materials (with multiple exciters) will be slightly quieter but result in a more full-range sound.

Adhesive dimensions: 21.5 mm (outside diameter) 21.75 mm (inside diameter)

To understand more about exciter technology, here is a link to the Exciters Buyers Guide .

Features

• Small size; just under 1-1/2" diameter, about 3/8" high
• Pre-applied 3M™ VHB™ adhesive for quick, durable installation
• Rare-earth neodymium motor with cooling vents for higher power handling
• 4 ohms impedance for use with small, Class D amplifiers
• Strategically-placed vent holes cool this exciters voice coil for higher power handling
