Dayton Audio - 83x23MM Planar Tweeter - PTMINI-6

Description

The Dayton Audio PTMini-6 is a miniature planar tweeter that is big on performance and sound quality! The 6-ohm impedance and incredibly small size make it an excellent choice for car audio or home use.

The clarity, definition, and transparency of a planar tweeter is unmatched by almost any other type of tweeter. Now Dayton Audio lets you build planar technology into more compact projects with the PTMini-6 planar tweeter! The surface-mount housing design can also be flush-mounted for a world of possible uses, such as a car A-pillar tweeter, a supertweeter for a full-range driver, a rear-mounted ambience tweeter, a conventional forward-facing tweeter configuration, or even a line array!

The membrane of a planar tweeter is an almost weightless ribbon of heat-resistant Kapton material and an etched aluminium conductor, enabling the performance of aluminium ribbon tweeters without the losses inherent in the transformer of a conventional ribbon tweeter. The result is a tweeter that is incredibly fast, dynamic, and smooth sounding with imperceptible distortion and excellent power handling. A crossover cut-off frequency of 4,000 Hz or higher is recommended with a 12dB/octave filter slope.

Features

• Compact planar ribbon tweeter driver
• High output and exceptional treble definition
• Surface or flush mount installation
• Potent neodymium magnetic design
• Supports 4,000 Hz crossover, 12dB/octave
