NB AUDIO - NPA DSP Plate Amplifiers

All plate amps are currently 'Out of Stock'. We're working on producing more stock, but the current ETA is approx. 2 weeks. If you would like to order one, get in touch with us at sales@nbaudio.com.au and we can add you to the next batch with a 10% deposit. Balance will be paid in full once it is shipped.

Description:

Introducing NB Audio's "NPA" (No Bullsh*t Plate Amplifier) range! Featuring the same Ultra-Low distortion NCORE amplifier technology found in our 'NAOS' amplifier combined with DSP for ultimate tuning and customisation. Our 'NPA' range takes one of the highest quality amplifier modules ever built, adds DSP and attaches it all onto a plate manufactured 100% in house using Australian Made aluminium for easy installation into speaker or subwoofer builds!

Hypex's Ncore technology has changed the way we see Class D amplification by overcoming many of the traditional limitations associated with Class D designs, such as high distortion and limited fidelity at higher frequencies. Unlike earlier Class D amplifiers, which were often criticized for lacking the warmth and clarity of Class A or AB designs, Ncore technology offers a combination of ultra-low distortion, high efficiency, and exceptional linearity across the frequency range. This breakthrough in switching amplifier design has redefined expectations, making Class D amplifiers viable for high-end audio applications where accuracy and sound quality are paramount. The result is an amplifier that not only delivers clean, powerful sound but also runs cooler and more efficiently, making it suitable for a wide range of audio setups.

The Range:

The NPA Plate Amplifier range includes various models designed to match different subwoofer driver power and impedance requirements.

All power ratings are at 0.1% THD+N @ 1khz (unless noted otherwise). For comparison, most plate amplifiers are advertised at 1% THD+N @ 1khz. 10x the distortion of our range of plate amplifiers.

Many manufacturers also quote max/peak/burst figures for their power ratings. All our power ratings are RMS/Continuous.

We've compiled an FAQ which elaborates on our range and will help you choose a suitable amplifier. You can find it here.

The NPA2500 has been delayed while we overcome hurdles associated with native implementation of Hypex DSP. Currently release date is unknown.

Backing Box:

Because our plate amps aren’t fully sealed by design, we offer an optional Backing Box that drops into place before installation. It’s designed to create an airtight rear chamber, and we include gasket tape to ensure a reliable seal against the enclosure.

These Backing Boxes are 3D printed in-house using HP-ASA, a high-performance, heat-resistant material rated to handle temperatures at least 20°C higher than what the plate amp will generate with intense use.

You can find them here.

Custom Plate Amplifier Options

As we handle the entire plate manufacturing process of our NPA Plate Amplifiers in-house, we’re able to offer fully custom plates tailored to your enclosure and design goals.

You can find out more here.

Features:

• Licensed Australian Made
• 5 Year Warranty
• Inputs:
  • NPA1200-8 - AES/EBU, Optical, RCA, SPDIF, XLR
  • Remainder of the range - RCA, XLR, High Level
• Cooling:
  • NPA1200-8 - Thermal adjusting fan
  • Remainder of the range - Passive Cooling
• IIR and FIR filter options
• 15 biquads per amplifier
• Three selectable presets for filters
• Source selection
• Signal detect
• Auto shutdown
• Clip protection
• Thermal protection
• Compatible with Hypex Remote Kit & Fusion OLED Screen

Specifications:

• Power ratings from 250 - 2500w
• THD+N: 0.0010-0.0020% at 50% max power
• Signal to Noise Ratio: 109db-111db
• Frequency Response: 10Hz - 48kHz +0/-3db
• Mains Input Voltage: 100-120Vac / 200-240Vac ±10%

Package Includes:

• Plate Amplifier
• AU Power Cable
• USB Type A to Mini USB Cable
• Pre-Terminated with 100cm of speaker wire
