Peerless - 1" Dome Tweeter Fabric - BC25TG15-08
Peerless - 1" Dome Tweeter Fabric - BC25TG15-08
Regular price
$44.95 AUD
Regular price
Sale price
$44.95 AUD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Description
The Peerless textile dome tweeters are renowned for their smooth, extended frequency response and high efficiency. Their textile dome diaphragm and ferrofluid-cooled voice coil minimise distortion and improve thermal handling, while the recess loaded faceplate allows for easy mounting and optimised dispersion. These tweeters deliver solid performance and are ideal for cost-effective Hi-Fi builds. Recommended cross-over frequency between 2.0KHz and 2.5KHz in speaker systems up to 80Wrms.
Features
- Sculpted, recessed-loaded round 4-hole faceplate.
- Smooth, extended response and high efficiency.
- 1" textile dome.
- Ferrofluid cooled voice coil.
Specifications
| Cms | 0.075mm/N |
|---|---|
| Coil | 25.4mmØ |
| Diam. | 104mmØ |
| Fs | 1100Hz |
| Impedance | 8Ω Re 6.7Ω |
| Le | 0.054mH |
| Manufacturer | Peerless |
| Materials | ASV |
| Mms | 0.255g |
| Power | 15Wrms |
| Qes | 1.66 |
| Qms | 3.15 |
| Qts | 1.1 |
| Re | 6.7Ω |
| Sd | 6.16cm² |
| Sens. | 91dB |
| Series | Peerless Dome Tweeter |
| Size | 1' |
| Vas | 0.004L |
| Zn | 8Ω |
| Hole | 70mmØ |
| Hole Cutout | 70mmØ |
| Type | Tweeter |
| Width | 104.3mmØ |
| Website Link | View Typhany Product Page |
