Peerless
Peerless - 1½" Full Range Driver - TC5FB00-04
Peerless - 1½" Full Range Driver - TC5FB00-04
Regular price
$23.95 AUD
Regular price
Sale price
$23.95 AUD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Description
The Peerless TC5FB00-04 is a compact 1½" full-range driver featuring a lightweight paper cone and ferrite magnet, engineered for solid acoustic performance in space-constrained designs. Its square frame with a round diaphragm allows for snug integration into tight enclosures, making it ideal for slim sound bars, portable Bluetooth speakers, desktop monitors, and other embedded audio applications.
Features
- Compact size, just 40.5 x 40.5mm, ideal for tight enclosures.
- Full range output covers 180 Hz to 20000 Hz.
- Lightweight paper cone, with PU surround.
- Reliable ferrite magnet for natural sound reproduction.
Specifications
| Cms | 0.870mm/N |
|---|---|
| Coil | 16.3mmØ |
| Diam. | 46mmØ |
| Fs | 250Hz |
| Hole | 36.5mmØ |
| Hole Cutout | 36.5mmØ |
| Impedance | 4Ω Re 3.2Ω |
| Le | 0.056mH |
| Manufacturer | Peerless |
| Mms | 0.471g |
| Power | 5Wrms |
| Qes | 2.43 |
| Qms | 4.64 |
| Qts | 1.6 |
| Re | 3.2Ω |
| Sd | 7.55cm² |
| Sens. | 78.3dB |
| Series | Peerless Full Range |
| Size | 1.5' |
| Type | Full Range |
| Vas | 0.07L |
| Width | 40.5mm |
| Zn | 4Ω |
| Website Link | View Typhany Product Page |
