SB Acoustics

SB Acoustics - 12" WNRX Subwoofer - SB34SWNRX-S75-6

SB Acoustics - 12" WNRX Subwoofer - SB34SWNRX-S75-6

Regular price $339.95 AUD
Regular price Sale price $339.95 AUD
Sale Sold out
Shipping calculated at checkout.

Description:

Hard Paper proprietary cone materials made in-house for consistency. Low damping SBR rubber surround with high exertion and resilience. Open structure cast frame for reduced reflections and compression. Aluminium alloy for light weight, non-magnetic (Low Le) and extra rigidity. Shorting Copper cap on pole piece. Non-inductive 75mm coil former. Heavy-duty high-temperature 4 layer voice coil version. Optimised for use as a sub woofer. Compatible with sealed, ported or with the SB34NRX-00 passive radiator.

Specifications:

Code SB34SWNRX-S75-6
Description SB Acoustics 12" Sub Woofer Aluminium Frame NRX Series
Type Subwoofer
Size 12"
Price Type each
Power 200Wrms
Coil 75.6mmØ
Width 346mmØ
QTY 1
Impedance 6.0Ω (Re 4.5Ω)
Depth 156mm
Mag. 2.1kg
Sens. 88dB
Re 4.5Ω
Qms 5
Qes 0.34
Qts 0.32
Vas 164L
Sd 508cm²
Cms 0.46mm/N
Fs 19Hz
Mms 154g
Zn
Le 3.0 mH
Rms 3.7kg/s
Diam. 305mmØ
Series Norex Cones
Manufacturer SB Acoustics
Materials Norex
Impedance (Ohm) 6 ohm
Power (RMS) 151-200 Watt
Inch 12
Bl 15.4Tm
Xmax 22.5mm
Flux (lm) 0.63T
Prms 200W
