SB Acoustics - 5" PFCR Coaxial - SB13PFCR25-4-COAX
SB Acoustics - 5" PFCR Coaxial - SB13PFCR25-4-COAX
Regular price
$88.95 AUD
Regular price
Sale price
$88.95 AUD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Description
25mm Voice coil, paper cone, rubber surround, ferrite motor, round mounting injection chassis, coaxial midwoofer. Vented reinforced plastic chassis. Proprietary cone material with natural fibres made in-house. Soft low damping rubber surround for improved transient response. Optimised motor system. Non-resonant long life lead wires. Compact large surround dome tweeter.
Features
- Vented reinforced plastic chassis.
- Proprietary cone material with natural fibres made in-house.
- Soft low damping rubber surround for improved transient response.
- Optimised motor system.
- Non-resonant long life lead wires.
- Compact large surround dome tweeter.
- Requires crossover (~3KHz ±1KHz)
Specifications
| Coil | 25.4mmØ |
|---|---|
| Fs | 43Hz |
| Le | 0.3mH |
| Mag. | 0.36kg |
| Mms | 9.1g |
| Power | 40Wrms |
| Qes | 0.3 |
| Qms | 2.26 |
| Qts | 0.27 |
| Re | 3.2Ω |
| Sd | 82cm² |
| Sens. | 90dB |
| Vas | 14.4L |
| Width | 150.5mmØ |
| Zn | 4+4Ω |
| Cms | 1.51mm/N |
| Rms | 1.1kg/s |
| Bl | 5.1Tm |
| Xmax | 9.3mm |
| Hole | 122mmØ |
| Hole Cutout | 122mmØ |
