SB Acoustics - 6.5" Satori TeXtreme Mid-Range - MR16TX-8
SB Acoustics - 6.5" Satori TeXtreme Mid-Range - MR16TX-8
Regular price
$524.95
Regular price
Sale price
$524.95
Unit price
per
Tax included.
Shipping calculated at checkout.
In stock
Stock status is updated regularly from my distributor. If the full quantity ordered isn’t available, I’ll get in touch.
Couldn't load pickup availability
Description
Satori 160mm, Textreme cone, rubber surround, neodymium motor, aluminium chassis 8 Ohm
Features
- Advanced TeXtreme® cone
- Vented aerodynamic cast aluminium chassis
- Inverted soft low damping rubber surround
- Advanced BIMAX spider
- Powerful optimised low distortion neodymium motor system
- Extended copper sleeve on pole piece
- Non-conducting fibreglass voice coil former
- Vented pole piece and voice coil
- Light weight CCAW voice coil
- Long life silver lead wires
Specifications
Specifications
General
| Driver type | Mid-Range |
|---|---|
| Nominal size | 6.5" |
| Nominal impedance | 8Ω |
| Series | Satori |
| Power handling (RMS) | 30 W |
| Sensitivity | 89 dB |
| Suggested alignment | Ported |
Thiele/Small parameters
| Resonant frequency (Fs) | 35 Hz |
|---|---|
| DC resistance (Re) | 6.2 Ω |
| Voice coil inductance (Le) | 0.11 mH |
| Mechanical Q (Qms) | 6.47 |
| Electrical Q (Qes) | 0.32 |
| Total Q (Qts) | 0.31 |
| Equivalent volume (Vas) | 39 L |
| Compliance (Cms) | 2 mm/N |
| Moving mass (Mms) | 10.3 g |
| Mechanical resistance (Rms) | 0.35 kg/s |
| Force factor (Bl) | 6.6 T·m |
| Effective piston area (Sd) | 117 cm² |
| Linear excursion (Xmax, one-way) | 2.85 mm |
| Displacement volume (Vd) | 33.34 cm³ |
| Efficiency bandwidth product (EBP) | 109.4 |
Motor
| Voice coil height | 10.7 mm |
|---|---|
| Air gap height | 5 mm |
| Magnetic flux density | 1.17 T |
| Magnet weight | 0.13 kg |
Mounting
| Overall diameter | 165 mm |
|---|---|
| Cutout diameter (suggested) | ≈ 141.3 mm |
| Mounting depth | 74.57 mm |
| Flange thickness | 7.52 mm |
| Bolt circle diameter | 153.5 mm |
| Mounting holes | 6 |
| Mounting hole diameter | 4.3 mm |
| Voice coil diameter | 35.5 mm |
| Weight | 1 kg |
Materials
| Cone | TeXtreme |
|---|---|
| Surround | Rubber |
| Voice coil former | Fibreglass |
| Basket | Cast Aluminium |
| Magnet | Neodymium |
- Xmax is quoted one-way (peak), not peak-to-peak.
- Sensitivity measured at 2.83V/1m.
Downloads
- 6½″ SATORI MR16TX-8 Datasheet
- MR16TX-8 Cutout & Recess Template (NB Audio) Straight off SB Acoustics' spec sheet: flange outline, recess depth, bolt holes. Scaled from SB Acoustics' drawing, so close but not guaranteed exact: cutout. Check it against your driver before you cut.
