SB Acoustics

SB Acoustics - 8" MFCL Subwoofer - SB23MFCL45-8

SB Acoustics - 8" MFCL Subwoofer - SB23MFCL45-8

Regular price $219.95 AUD
Regular price Sale price $219.95 AUD
Sale Sold out
Tax included. Shipping calculated at checkout.

Description:

Vented cast aluminium chassis for optimum strength and low compression. Unique mineral filled polypropylene cone material, made in-house with extra stiffness. Extended roll rubber surround for improved transient response and SPL. Non-conducting fibre glass CCAW voice coil former. Long life silver lead wires. Vented pole piece and aluminium chassis. Optimised for compact enclosures.

Features:

  • Long stroke design
  • Linear high stability suspension
  • Low damping rubber surround
  • Long copper voice coil
  • Non-conducting reinforced fibre glass coil former
  • Very stiff mineral filled Polypropylene cone
  • Vented cast aluminium chassis
  • Large vented motor system
  • Long life silver lead wires
  • Optimized for smaller enclosures

Specifications:

Code SB23MFCL45-8
Type Subwoofer
Size 8"
Power 150Wrms
Coil 45.5mmØ
Width 234mmØ
Impedance 8Ω (Re 6.2Ω)
Depth 137.7mm
Mag. 2kg
Sens. 85dB
Re 6.2Ω
Qms 7.3
Qes 0.46
Qts 0.43
Vas 37L
Sd 210cm²
Cms 0.59mm/N
Fs 28.5Hz
Mms 53g
Zn
Le 1.02mH
Rms 1.3kg/s
Diam. 187mmØ
Series Poly Cone
Manufacturer SB Acoustics
Materials Polypropylene
Impedance (Ohm) 8 ohm
Power (RMS) 101-150 Watt
Bl 11.3Tm
Xmax 21.2mm
Flux (lm) 1.03T
