Scan-Speak
Scan-Speak - ¾" Automotive Ring Radiator Tweeter - R1904/613001
Scan-Speak - ¾" Automotive Ring Radiator Tweeter - R1904/613001
Regular price
$109.95 AUD
Regular price
Sale price
$109.95 AUD
Unit price
/
per
Tax included.
Shipping calculated at checkout.
Couldn't load pickup availability
Description
19mm Ring Radiator 4ohm, Neo Magnet, Wedge House & Nut, Grill from the Discovery range. Highly compact 42mm diameter with 8mm protrusion allows discrete flush mounting in dashboards / pillars / doors etc. Supplied with wedge shaped housing for surface mount applications. The frequency response is optimised for in car use. Rated at 40 watts rms.
Features
- 3/4" Ring Dome tweeter under a grille
- Optimized for Car use and installation
- Compact mounting dimensions
- Flange and Nut for door panel mounting
- Wedge House for dashboard mounting
Specifications
| Impedance | 4Ω Re 4.3Ω |
|---|---|
| Fs | 1000Hz |
| Power | 40Wrms |
| Sens. | 87.0dB |
| Qes | 2.02 |
| Qms | 8.03 |
| Qts | 1.61 |
| Vas | 0.002L |
| Cms | 0.11mm/N |
| Coil | 19mmØ |
| Le | 0.02mH |
| Mag. | 0.05kg |
| Manufacturer | Scan-speak |
| Mms | 0.23g |
| Re | 3.3Ω |
| Rms | 0.18kg/s |
| Sd | 3.8cm² |
| Series | Automotive |
| Size | 1' |
| Type | Tweeter |
| Width | 42mm |
| Zn | 4Ω |
