Dayton Audio

Dayton Audio - 250W DSP Plate Amplifier - SPA250DSP

Dayton Audio - 250W DSP Plate Amplifier - SPA250DSP

Regular price $589.95
Regular price Sale price $589.95
Sale Sold out
Tax included. Shipping calculated at checkout.

In stock

Stock status is updated regularly from my distributor. If the full quantity ordered isn’t available, I’ll get in touch.

View full details

Description:

The Dayton Audio SPA250DSP digitally processed plate amplifier offers an elite level of control over your entire system (i.e. subwoofer and mains). This unique amplifier allows you to fine tune your systems low-frequency performance, and at the same time high pass to your mains (or satellites) protecting them from damage due to over excursion. DSP functions include: 7 PEQs, LPF, phase, subsonic filter, limiter, mains delay, and HPF. Fast, intuitive PC-based GUI software enables full access to the DSP functions.

Dayton Audio's SPA250DSP true 250 watt digital switching plate amplifier features advanced signal processing control that every audio enthusiast wants. This power and flexibility is accessible via PC-GUI software and the innovative single-knob LCD control panel.

Features:

  • DSP functions: 7 PEQs, LPF, phase, subsonic filter, limiter, mains delay, and HPF
  • Single-knob control panel with high-contrast LCD display and status LEDs
  • Fast, intuitive PC-based GUI software enables full access to the DSP functions
  • Efficient Class D output topology ensures high-impact low frequency performance

Specifications:

  • 250 watts RMS into 4 ohms, THD+N <0.1%
  • Signal to noise ratio: 97.9 dB (A-weighted)
  • Amplifier cutout: 235mmx160mm
  • Shipping weight: 1.68kg

Specifications

Power output

Into 4 Ω 250 W
Minimum load 4 Ω (assumed: Dayton Audio doesn't state one)
Amplifier class D

Controls and processing

DSP Yes
DSP functions Low-pass, subsonic filter, 5-band PEQ (PC software), 2 PEQ bands on the panel, limiter, high-pass on the line out, delay on the line out
Low-pass filter 30 – 125 Hz
Low-pass slope 12 or 24 dB/octave, or off
Subsonic filter 25 – 40 Hz
Subsonic slope 12 or 24 dB/octave, or off
Phase Variable, 0–180°
Parametric EQ 5 bands: 10–200 Hz (PC software); 2 on the panel
High-pass on the line out 30 – 125 Hz
Line-out delay 0 – 10 ms

Inputs and outputs

Inputs RCA line in, L/R (unbalanced); XLR in, L/R (balanced)

Size and mounting

Plate (W × H) 184 × 262 mm
Cutout (W × H) 158.8 × 234.9 mm
Weight 1.1 kg

Power supply

Mains 230–240 V AC

Performance

Signal-to-noise ratio (A-weighted) 97.9 dB
  • Power as Dayton Audio rates it (RMS).

Some figures here aren't checked against Dayton Audio's datasheet yet. See which
